Experience the pinnacle of 3D printed EDF performance with the Ventus Pro. This 64mm powerhouse combines sleek aerodynamics with an integrated thrust vectoring system for unprecedented maneuverability. Choose your flight style—fly conventional for speed and efficiency, or engage the 3-dimensional thrust vectoring for post-stall aerobatics and impossible maneuvers. With a 675mm wingspan and 900-1.1kg flying weight, the Ventus Pro delivers exceptional thrust-to-weight ratio. The modular design features snap-fit wings and tail fins for field repairs, while the replaceable nose cone switches between FPV systems or line-of-sight with simple M2 screws. The print-in-place vectoring nozzle opens up a new dimension of control.
Key Features
- Thrust Vectoring Included - Integrated 2-axis nozzle included with the kit
- Modular Design - Snap-fit wings and tail fins allow for tool-free field assembly and transport
- FPV Compatible - Interchangeable nose cones support DJI O3, Walksnail, and analog systems
- Filament Alignment - Uses filament segments for precise alignment of fuselage sections during assembly
- Universal FC Tray - Compatible with SpeedyBee and other flight controllers
- FPV Ready - DJI O3 and Walksnail Pro compatible
- Zephyr Manual Viewer – The ultimate build companion for Mac and Windows. Ditch static PDFs for fully interactive 3D guides. Rotate models, identify parts instantly, and follow clear step-by-step assembly instructions to build your aircraft with confidence
Specifications
Ventus Pro Build
| Wingspan | 675mm |
| Length | 742mm |
| Weight | 900-1.1kg |
Required Parts
Ventus Pro Build
- XFly 64mm 4S EDF unit
- 50A+ ESC
- 2× EMAX ES08MAII servos (control surfaces)
- 2× EMAX ES08 servos (thrust vectoring)
- Flight controller (SpeedyBee F405 compatible)
- 1500mAh+ 4S LiPo battery
- SBUS receiver
- 1.3-2mm pushrods (control surfaces)
- M2 ball joints & pushrods (thrust vectoring)
- M2 screws (nose cone/battery tray/servo cover)
- 2 x [8×3mm] magnets
- Velcro straps
- LW-PLA (main structure)
- PLA+ (reinforced components)
- TPU 95A (hinges)
- PETG (snap-fit connectors)
Optional Components
- Optional FPV: DJI O3 or Walksnail Pro system
- Switch configurations with M2 screws
What's Included
3D Print Files — Includes all STL files needed for printing
Quick-Start Pack — Includes profiles for 14 printers, test parts, and modifier guides
Manuals & Viewer — Includes PDF Manual and Zephyr Manual Viewer (Interactive 3D App)
