Park-cruiser, pylon-bruiser, or full-send speed machine — same airframe, three EDF sizes, two looks. The F-87 kit lets you choose your timeline: build the Astral Thunder, a sleek interceptor from a golden age of aviation, or the Cosmic Predator, a 'Mad Max' style racer from a gritty future. Both cosmetic variants are included, allowing you to pick your power level and flip between the clean lines of a retro-future jet or the aggressive look of a reno racer.
Key Features
- Alternate History Lore - Pilot the interceptor from a timeline that never was
- Dual Cosmetic Variants - swap between Astral Thunder and Cosmic Predator looks
- Filament Alignment - Uses filament segments for precise alignment of fuselage sections during assembly
- Three Sizes - Choose between 30mm,40mm, and 50mm EDF
- Zephyr Manual Viewer – The ultimate build companion for Mac and Windows. Ditch static PDFs for fully interactive 3D guides. Rotate models, identify parts instantly, and follow clear step-by-step assembly instructions to build your aircraft with confidence
Specifications
30mm Version
| Wingspan | 440mm |
| Length | 514mm |
| Weight | 260g |
| Power | 3S LiPo |
40mm Version
| Wingspan | 587mm |
| Length | 690mm |
| Weight | 500g |
| Power | 4S LiPo |
50mm Version
| Wingspan | 587mm |
| Length | 690mm |
| Weight | 600g |
| Power | 4S LiPo |
Required Parts
30mm Version
- XFly 30mm 3S EDF
- 15A Mantis or 20A XFly ESC
- 3× DSPower 2g servos
- 650mAh 3S LiPo (Tattu)
- Receiver of choice
- 4mm Carbon Tube (400mm wing + 100mm stab)
40mm Version
- XFly 40mm 4S EDF
- 30-40A ESC
- 3× 4.3g servos
- 850mAh 4S LiPo
- Receiver of choice
- 6mm Carbon Tube (400mm wing + 100mm stab)
50mm Version
- XFly 50mm 4S EDF
- 40-50A ESC
- 3× 4.3g or 5g servos (Metal Gear preferred)
- 1500-2200mAh 4S LiPo
- Receiver of choice
- 6mm Carbon Tube (Total 750mm: 500mm wing / 115mm tail / 135mm stab)
Shared Components
- CA glue (medium) + hot glue
- Masking tape for servo covers
- TPU 95A for hinges
- LW-PLA (ColorFabb/eSUN active-foam) for structure
- PLA+ for control surfaces
- Velcro
- RadioMaster Boxer recommended (any TX works)
What's Included
3D Print Files — Includes all STL files needed for printing
Quick-Start Pack — Includes profiles for 14 printers, test parts, and modifier guides
Manuals & Viewer — Includes PDF Manual and Zephyr Manual Viewer (Interactive 3D App)
